TIE ROD END TE-13112L

MASUMA No.
ME-K4001L
TOMOI No.
TE-13112L
TRW No.
JTE7692
555 No.
SE-K8051L
CTR No.
CE0-320L

High Security

Boost Motivation

In-situ Installation

Stable And Durable

OEM List
  • 56820-38000
  • 57780-38000

TOMOI tie rod ends are manufactured using modern non-disassemblable technology. Ball joint parts of the ends are made of Cr40 alloy steel with hardening. Mirror processing technology ensures the surface roughness of the ball pin is no more than 0.4 microns, which significantly increases the service life of the joint. The design and processing technology of the ball joint guarantee that even under high angular loads, the ball joint will not jump out of the standard seat.

TOMOI is a global brand of spare parts, components and consumables for cars. The main specialization of the brand: resource parts for post-warranty service of Asian and European cars. The company’s strategy is to offer consumers the best ratio of reliability and price of spare parts.

HYUNDAI
SONATA IV
Chassis No.YearConfiguration
2.0L G4JP. SEDAN1998.01-1999.012.0L Patrol G4JP MPI (136 hp / 100 kW) Front - wheel drive (2WD). LHD
2000cc. G6BP. SEDAN. БЕНЗИН. MPI. SEDAN1998.01-1999.012.0L Patrol G6BP (136 hp / 100 kW) Front - wheel drive (2WD). LHD
2.4L G4BS. SEDAN1998.01-1999.012.4L Patrol G4BS MPI (143 hp / 105 kW) Front - wheel drive (2WD). LHD
2.5L DELTA. G6BV. SEDAN. SEDAN1998.01-1999.012.5L Patrol G6BV (160 hp / 118 kW) Rear - wheel drive. LHD
2500cc. G6BV. БЕНЗИН. MPI. SEDAN1998.01-1999.012.5L Patrol G6BV (160 hp / 118 kW) Front - wheel drive (2WD). LHD
2000cc. G6BP. SEDAN. БЕНЗИН. MPI. SEDAN1999.01-2001.012.0L Patrol G6BP (136 hp / 100 kW) Front - wheel drive (2WD). LHD
2500cc. G6BV. БЕНЗИН. MPI. SEDAN1999.01-2001.012.5L Patrol G6BV (160 hp / 118 kW) Front - wheel drive (2WD). LHD
2.0L G4JP. SEDAN1999.01-2001.042.0L Patrol G4JP MPI (136 hp / 100 kW) Front - wheel drive (2WD). LHD
2.4L G4BS. SEDAN1999.01-2001.042.4L Patrol G4BS MPI (143 hp / 105 kW) Front - wheel drive (2WD). LHD
2.5L DELTA. G6BV. SEDAN. SEDAN1999.01-2001.042.5L Patrol G6BV (160 hp / 118 kW) Rear - wheel drive. LHD
2000cc. G6BP. SEDAN. БЕНЗИН. MPI. SEDAN2001.01-2005.112.0L Patrol G6BP (136 hp / 100 kW) Front - wheel drive (2WD). LHD
2500cc. G6BV. БЕНЗИН. MPI. SEDAN2001.01-2005.112.5L Patrol G6BV (160 hp / 118 kW) Front - wheel drive (2WD). LHD
2.0L G4JP. SEDAN2001.04-2004.112.0L Patrol G4JP MPI (131 hp / 96 kW) Front - wheel drive (2WD). LHD
2.7L DELTA. G6BA. SEDAN2001.04-2004.112.7L Patrol G6BA (172 hp / 126 kW) Rear - wheel drive. LHD
2.7L DELTA. G6BA. RUSSIA. SEDAN2004.04-2006.012.7L Patrol G6BA (172 hp / 126 kW) Rear - wheel drive. LHD
2.0L G4JP. SEDAN. RUS2004.04-2006.042.0L Patrol G4JP MPI (131 hp / 96 kW) Rear - wheel drive. LHD
KIA
MAGENTIS I
Chassis No.YearConfiguration
2.0L G4JP. SEDAN2000.12-2005.092.0L Patrol G4JP MPI (145 hp / 107 kW) Front - wheel drive (2WD). LHD
2.5L DELTA. G6BV. SEDAN. SEDAN2000.12-2005.092.5L Patrol G6BV (169 hp / 124 kW) Front - wheel drive (2WD). LHD
